Intel Desktop Board D945PLNM Technical Product Specification
60
2.10.3 Fan Connector Current Capability
CAUTION
The processor fan must be connected to the processor fan connector, not to a chassis fan
connector. Connecting the processor fan to a chassis fan connector may result in onboard
component damage that will halt fan operation.
Table 29 lists the current capability of the fan connectors.
Table 29. Fan Connector Current Capability
Fan Connector Maximum Available Current
Processor fan 3.0 A
Front chassis fan 1.5 A
Rear chassis fan 1.5 A
2.10.4 Power Supply Considerations
CAUTION
The +5 V standby line for the power supply must be capable of providing adequate +5 V standby
current. Failure to do so can damage the power supply. The total amount of standby current
required depends on the wake devices supported and manufacturing options.
System integrators should refer to the power usage values listed in Table 28 when selecting a power
supply for use with the board.
Additional power required will depend on configurations chosen by the integrator.
The power supply must comply with the following recommendations found in the ATX form factor
specification:
The potential relation between 3.3 VDC and +5 VDC power rails
The current capability of the +5 VSB line
All timing parameters
All voltage tolerances
