Intel Desktop Board D955XBK Product Guide
10
Table 1. Feature Summary (continued)
Peripheral Interfaces
• One front panel audio header (yellow)
• Up to eight USB 2.0 ports
⎯ Four ports routed to the back panel
⎯ Four ports routed to two USB headers
• Up to eight Serial ATA channels (one device per channel)
— Four RAID capable Serial ATA (3.0 Gb/s) connectors (black) via the
ICH7R
— Four RAID capable Serial ATA (SATA) connectors (blue) via the discrete
controller
• Up to three IEEE 1394 ports:
⎯ One IEEE 1394a port routed to the back panel
⎯ One IEEE 1394a header (blue)
⎯ One IEEE 1394b header (pink)
• One IDE interface with ATA-66/100 support
• One diskette drive interface
• One parallel port
• One serial port
• RJ-45 LAN port
• PS/2* keyboard and mouse ports
Power Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, PCI Express, PS/2, LAN, and front panel
Hardware Management
Hardware monitor with:
• Four fan sensing inputs used to monitor fan activity
• Remote diode temperature sensing
• Intel
®
Precision Cooling Technology fan speed control
• Voltage sensing to detect out of range values
Related Links
For more information about Intel Desktop Board D955XBK, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to:
http://support.intel.com/support/motherboards/desktop/
Supported Operating Systems
The desktop board supports the following operating systems:
• Microsoft Windows* XP Professional
• Microsoft Windows XP Home
• Microsoft Windows XP Media Center Edition 2005
• Microsoft Windows 2000
