Desktop Board Features
15
Main Memory
NOTE
To be fully compliant with all applicable Intel
®
SDRAM memory specifications, the
board should be populated with DIMMs that support the Serial Presence Detect (SPD)
data structure. If your memory modules do not support SPD, you will see a
notification to this effect on the screen at power up. The BIOS will attempt to
configure the memory controller for normal operation.
The Desktop Board supports the dual or single channel memory configurations defined
below:
• Four 240-pin Double Data Rate 3 (DDR3) SDRAM Dual Inline Memory Module
(DIMM) connectors with gold-plated contacts
• Support for:
⎯ 1.5 V Non-ECC, DDR3 1333 (over clocked)/1066/800 MHz memory
⎯ Serial Presence Detect (SPD) memory only
⎯ Unbuffered, non-registered single- or double-sided DIMMs (except double-sided
DIMMs with x16 organization)
⎯ Memory configurations listed below:
• Up to 4 GB utilizing 512 Mb or 1 Gb technology
• Up to 8 GB utilizing 1 Gb or 2 Gb technology
• A minimum of 512 MB of total memory is required
CAUTION
Altering PC memory frequency, voltage and/or latency may: (i) reduce system stability
and useful life of the system, memory and processor; (ii) cause the processor and
other system components to fail; (iii) cause reductions in system performance; (iv)
cause additional heat or other damage; and (v) affect system data integrity. Intel has
not tested, and does not warranty, the operation of the memory beyond its
specifications. Intel assumes no responsibility that the memory, including if used with
altered clock frequencies and/or voltages, will be fit for any particular purpose. Check
with the memory manufacturer for warranty and additional details.
NOTE
System resources and hardware (such as PCI Express devices) require physical
memory address locations that can reduce available addressable system memory.
This could result in a reduction of as much as 1 GB or more of physical addressable
memory being available to the operating system and applications, depending on the
system configuration and operating system.
