Intel Desktop Board DH55PJ Technical Product Specification
40
Table 9. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A PCI Conventional bus add-in card connector
B PCI Express x1 bus add-in card connector
C PCI Express x1 bus add-in card connector
D PCI Express x16 bus add-in card connector
E 12 V internal power connector (ATX12V)
F Rear chassis fan header
G Processor fan header
H Front chassis fan header
I Main power connector (2 x 12)
J Parallel port header
K Chassis intrusion header
L SATA connectors
M Alternate front panel power LED header
N Front panel header
O USB headers (3)
P Serial port header
Q S/PDIF header
R Front panel audio header
S Internal mono speaker header

Intel DH55PJ Specifications

General

Form Factor	Micro ATX
Socket	LGA 1156
Memory Type	DDR3
Maximum Memory	8 GB
Memory Slots	2
PCI Express x16	1
PCI Express x1	2
PCI Slots	1
Chipset	Intel H55 Express
USB Ports	12
Video Outputs	VGA
SATA Ports	6
