Intel Desktop Board DH55PJ Technical Product Specification
64
3.6 Boot Options
In the BIOS Setup program, the user can choose to boot from a hard drive, optical
drive, removable drive, or the network. The default setting is for the optical drive to
be the first boot device, the hard drive second, removable drive third, and the network
fourth.
3.6.1 Optical Drive Boot
Booting from the optical drive is supported in compliance to the El Torito bootable
CD-ROM format specification. Under the Boot menu in the BIOS Setup program, the
optical drive is listed as a boot device. Boot devices are defined in priority order.
Accordingly, if there is not a bootable CD in the optical drive, the system will attempt
to boot from the next defined drive.
3.6.2 Network Boot
The network can be selected as a boot device. This selection allows booting from the
onboard LAN or a network add-in card with a remote boot ROM installed.
Pressing the <F12> key during POST automatically forces booting from the LAN. To
use this key during POST, the User Access Level in the BIOS Setup program's Security
menu must be set to Full.
3.6.3 Booting Without Attached Devices
For use in embedded applications, the BIOS has been designed so that after passing
the POST, the operating system loader is invoked even if the following devices are not
present:
• Video adapter
• Keyboard
• Mouse
3.6.4 Changing the Default Boot Device During POST
Pressing the <F10> key during POST causes a boot device menu to be displayed. This
menu displays the list of available boot devices. Table 35 lists the boot device menu
options.
Table 35. Boot Device Menu Options
Boot Device Menu Function Keys Description
<↑> or <↓>
Selects a default boot device
<Enter> Exits the menu, and boots from the selected device
<Esc> Exits the menu and boots according to the boot priority
defined through BIOS setup

Intel DH55PJ Specifications

General

Form Factor	Micro ATX
Socket	LGA 1156
Memory Type	DDR3
Maximum Memory	8 GB
Memory Slots	2
PCI Express x16	1
PCI Express x1	2
PCI Slots	1
Chipset	Intel H55 Express
USB Ports	12
Video Outputs	VGA
SATA Ports	6

Summary

Product Description and Features

Overview

Provides a general overview of the Intel Desktop Board DH55PJ.

Feature Summary

Summarizes the major features of the motherboard.

Board Layout

Illustrates the physical layout of major components on the motherboard.

Block Diagram

Depicts the major functional areas and interconnections of the motherboard.

System Components and Configuration

Processor

Describes supported processors and their specifications.

Chipset and Memory

Details the H55 chipset and system memory features.

Memory Configurations

Explains dual channel (interleaved) and single channel (asymmetric) memory modes.

Legacy Considerations

Details differences from other Intel Desktop Board products and legacy features.

Online Support

Provides web links for product information, support, and drivers.

Graphics, Audio, Networking, and Storage

Graphics Subsystem

Covers integrated graphics support, including VGA and DVI-D outputs.

Integrated Graphics

Details integrated graphics support via Intel Flexible Display Interface.

PCI Express x16 Graphics

Details support for discrete add-in graphics cards via PCIe x16.

USB and SATA Interfaces

Describes USB ports and internal SATA connectors.

LAN Subsystem

Details the Gigabit Ethernet controller and RJ-45 connector.

Audio Subsystem

Covers audio features, codec, and capabilities.

System Management, Power, and Hardware

Hardware Management

Lists hardware management features like monitoring and fan control.

Thermal Monitoring

Shows locations of thermal sensors and fan headers.

Power Management

Explains power management implementation levels.

ACPI and Power States

Explains ACPI and supported system power states.

Wake-up Features

Details devices and events that can wake the computer from sleep states.

Connectors, Jumpers, and Electrical

Board Connectors and Headers

Introduces board connectors and headers, including back panel and component-side.

Connector Signal Details

Provides pinout and signal names for various port headers.

Front Panel Interfaces

Covers front panel header, controls, LEDs, and USB headers.

Jumper Block

Explains the location and function of the BIOS setup jumper block.

Electrical and Power Supply Considerations

Discusses power supply requirements, ATX compliance, and current ratings.

BIOS Features and Updates

BIOS Introduction and Features

Introduces the Intel BIOS, its storage, POST messages, and menu structure.

BIOS Updates and Recovery

Describes utilities for updating the BIOS and procedures for BIOS recovery.

Boot Options

Covers booting from various devices like hard drive, optical, network, and removable media.

BIOS Security Features

Explains supervisor and user passwords for BIOS and boot security.

Troubleshooting and Diagnostics

BIOS Error Codes

Lists and explains BIOS beep codes, LED blink codes, error messages, and POST codes.

Regulatory Compliance and Safety

Regulatory Compliance

Provides information on safety, EMC, and product certifications.

Safety and Environmental Information

Covers safety standards, environmental specs, and energy compliance.

Battery Disposal Information

Provides cautions and guidelines for battery replacement and disposal.
