Intel Desktop Board DH61BE Product Guide
14
Online Support
For more information on Intel Desktop Board DH61BE consult the following online
resources:
• Intel Desktop Board DH61BE http://www.intel.com/products/motherboard/index.ht
m
• Desktop Board Support http://www.intel.com/p/en_US/support?iid=hdr+supp
ort
• Available configurations for Intel
Desktop Board DH61BE
http://ark.intel.com
• Supported processors http://processormatch.intel.com
• Chipset information http://www.intel.com/products/desktop/chipsets/inde
x.htm
• BIOS and driver updates http://downloadcenter.intel.com/
• Integration information http://www.intel.com/support/go/buildit
Processor
CAUTION
Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2 pin)
power connector to the Desktop Board may result in damage to the board, or the
system may not function properly.
Intel Desktop Board DH61BE supports Intel Core i7, Intel Core i5, Intel Core i3, and
Intel Pentium processors in the LGA1155 package. Processors are not included with
the Desktop Board and must be purchased separately. The processor connects to the
Desktop Board through an LGA1155 socket.
For information on supported processors for Intel Desktop Board DH61BE, go
to http://processormatch.intel.com
.

Intel DH61BE Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCI Express x16	1
PCIe 2.0 x1 Slots	2
SATA Ports	4
RAID Support	No
Ethernet	10/100/1000 Mbps
Onboard Video	Yes
Video Output	DVI, VGA
