Intel DH61BE Product Guide

Intel Desktop Board DH61BE Product Guide
34
3. Rotate the socket lever to lift the load plate away from the socket (Figure 8, A).
Make sure that the load plate is in the fully open position (Figure 8, B) while being
careful not
to damage adjacent components. Do not touch the socket contacts.
Figure 8. Lift the Load Plate

Intel DH61BE Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCI Express x16	1
PCIe 2.0 x1 Slots	2
SATA Ports	4
RAID Support	No
Ethernet	10/100/1000 Mbps
Onboard Video	Yes
Video Output	DVI, VGA
