Intel Desktop Board DZ77BH-55K Technical Product Specification
30
1.9 LAN Subsystem
The LAN subsystem consists of the following:
• Intel 82579V Gigabit Ethernet Controller (10/100/1000 Mb/s)
• Intel Z77 Express Chipset
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between the PCH and the LAN controller
• Conventional PCI bus power management
 ACPI technology support
 LAN wake capabilities
• LAN subsystem software
For information about Refer to
LAN software and drivers http://downloadcenter.intel.com
1.9.1 Intel
®
82579V Gigabit Ethernet Controller
The Intel 82579V Gigabit Ethernet Controller supports the following features:
• 10/100/1000 BASE-T IEEE 802.3 compliant
• Energy Efficient Ethernet (EEE) IEEE802.3az support (Low Power Idle [LPI] mode)
• Dual interconnect between the Integrated LAN Controller and the Physical Layer
(PHY):
 PCI Express-based interface for active state operation (S0) state
 SMBUS for host and management traffic (Sx low power state)
• Compliant to IEEE 802.3x flow control support
• 802.1p and 802.1q
• TCP, IP, and UDP checksum offload (for IPv4 and IPv6)
• Full device driver compatibility
• Provides lower power usage to meet Energy Star 5.0 and ErP specifications
