Intel DZ77BH-55K - SATA Connectors; Dual-Port Front Panel USB 2.0 Headers; Front Panel USB 3.0 Connector

Intel Desktop Board DZ77BH-55K Technical Product Specification
52
Table 20. SATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 21. Dual-Port Front Panel USB 2.0 Headers
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
Table 22. Front Panel USB 3.0 Connector
Pin Signal Name Description
1 Vbus Power
2 IntA_P1_SSRX− USB3 ICC Port1 SuperSpeed Rx−
3 IntA_P1_SSRX+ USB3 ICC Port1 SuperSpeed Rx+
4 GND Ground
5 IntA_P1_SSTX− USB3 ICC Port1 SuperSpeed Tx−
6 IntA_P1_SSTX+ USB3 ICC Port1 SuperSpeed Tx+
7 GND Ground
8 IntA_P1_D− USB3 ICC Port1 D− (USB2 Signal D−)
9 IntA_P1_D+ USB3 ICC Port1 D+ (USB2 Signal D+)
10 ID Over Current Protection
11 IntA_P2_D+ USB3 ICC Port2 D+ (USB2 Signal D+)
12 IntA_P2_D− USB3 ICC Port2 D− (USB2 Signal D−)
13 GND Ground
14 IntA_P2_SSTX+ USB3 ICC Port2 SuperSpeed Tx+
15 IntA_P2_SSTX− USB3 ICC Port2 SuperSpeed Tx−
16 GND Ground
17 IntA_P2_SSRX+ USB3 ICC Port2 SuperSpeed Rx+
18 IntA_P2_SSRX− USB3 ICC Port2 SuperSpeed Rx+
19 Vbus Power
20 Key No pin
