Intel Desktop Board DZ77GA-70K Technical Product Specification
14
Table 2. Feature Summary (continued)
Peripheral
Interfaces
• Eight USB 3.0 ports:
― Four ports implemented with stacked back panel connectors (blue)
― Four ports implemented through two dual-port internal connectors (blue)
• Eight USB 2.0 ports:
― Four ports implemented with stacked back panel connectors (two black
and two orange high current charging ports)
― Four front panel ports are implemented through two dual-port internal
headers
• Nine Serial ATA (SATA) ports:
― Two SATA 6.0 Gb/s interfaces through the Intel Z77 Express Chipset with
Intel
®
Rapid Storage Technology RAID support (blue)
― Two SATA 6.0 Gb/s interfaces through a Marvel 88SE9172 controller
(gray)
― One back panel eSATA 6.0 Gb/s port through a Marvel 88SE9172
controller (red)
― Four internal SATA 3.0 Gb/s interfaces through the Intel Z77 Express
Chipset with Intel Rapid Storage Technology RAID support (black)
• Two IEEE 1394a ports:
― One port via a back panel connector
― One port via a front-panel header (blue)
Wireless Module
•
Separate module that provides both Bluetooth* and WiFi included with the
desktop board
BIOS
•
Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express* Revision 2.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, CIR and USB ports
LAN Support
Two Gigabit (10/100/1000 Mb/s) LAN subsystems using the Intel
82579
Gigabit Ethernet Controller and Intel
®
82574 Gigabit Ethernet Controller
Expansion
Capabilities
• Two PCI Express 3.0 x16 bus add-in card connectors from the processor (2
PCI Express slot is electrically x8)
• One PCI Express 2.0 x4 bus add-in card connector from the PCH
• Two PCI Express 2.0 x1 bus add-in card connectors from the PCH
• Two Conventional PCI bus add-in card connectors from the PCH via a PCI
bridge
Note: PCI Express 3.0 is only supported by 3
rd
generation Intel Core
processor family processors
Hardware Monitor
Subsystem
• Hardware monitoring and fan control through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Four fan headers using PWM control
• Four fan sense inputs used to monitor fan activity
• Fan speed control using voltage control (4-pin fan headers front, rear, and
auxiliary) with selectable support in BIOS for 3-wire fans
• Support for Platform Environmental Control Interface (PECI)
