Intel Desktop Board DZ77GA-70K Technical Product Specification
34
1.10 Bluetooth*/WiFi Module
The WiFi/Bluetooth* module is supplemental hardware that is included with certain
Desktop Boards (see Figure 6).
Figure 6. Bluetooth/WiFi Module
1.10.1 Bluetooth Technology (Module)
The Bluetooth Module enables the user to connect with a variety of Bluetooth enabled
devices. Driver support is provided by Microsoft operating systems like Microsoft Vista
and Microsoft Windows 7. The Bluetooth driver stack is supplied by Microsoft but some
Bluetooth enable devices might provide additional Bluetooth features and for proper
functioning of those features, will need their own supplied drivers installed.
• CSR Bluetooth module (BC0401PC08)
• Maximum data rate 3.0 Mb/s
• Forward and backward compatibility with Bluetooth v1.1, v1.2, v2.0, and v2.1
• Integrated Antenna
• Operating system support (Windows XP, Windows Vista, and Windows 7 both 32 bit
and 64 bit)
For information about Refer to
Obtaining Bluetooth information and drivers http://msdn.microsoft.com/en-
us/library/aa362932(VS.85).aspx

Intel DZ77GA-70K Specifications

General

Form Factor	ATX
Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4
Max Memory	32 GB
SATA 6Gb/s Ports	4
SATA 3Gb/s Ports	4
USB 3.0 Ports	4
USB 2.0 Ports	8
CrossFire Support	Yes
SLI Support	Yes
Memory Speed	DDR3 1600/1333/1066
PCI Express x16 Slots	2
PCI Express x1 Slots	2
LAN	Intel 82579V Gigabit Ethernet
Audio	7.1 Channel High Definition Audio
RAID Support	RAID 0, 1, 5, 10
PCI Slots	2
