Intel Galileo Tutorial Guide

Intel® Galileo Development Kit for IoT - Tutorial Guide Revision 1.0 – 20-Feb-2014
(Page 10 of 32)
5. Use the ‘diskutil unmountdisk’ command along with the device node captured in the
previous step to unmount all partitions found on the USB key e.g.
Figure 5: Unmount disk on Mac
6. Use the ‘chmod’ command along with the device node captured in the previous step to make
the USB key device accessible by a non-root user
Figure 6: Make disk accessible on Mac
7. Create a VirtualBox virtual disk file corresponding to the DevKit USB key using the VBoxManage
command as shown below. Please note you will need to change the path where you wish the
file to be stored and use the device node captured in step 10 above
VBoxManage internalcommands createrawvmdk -filename /Users/todorminchev/Desktop/devkit.vmdk -
rawdisk /dev/disk4
Figure 7: Create Virtual disk on Mac
NOTE : Back up your virtual disk file (e.g. devkit.vmdk) to a safe location. You might need
to refer to it in the future in case that your virtual machine gets corrupted.
8. You are now ready to create your virtual machine. Use the ‘diskutil unmountdisk’ command to
unmount the USB key again (please see step 5 above).

Intel Galileo Specifications

General

Product family	Intel Galileo
Product series	Intel Galileo board
Processor cache	16 KB
Processor cores	1
Processor model	Intel Quark SoC X1000
64-bit computing	No
Processor socket	Quark 393pin FCPGA
Product codename	-
Processor frequency	400 MHz
Microcontroller model	Intel Quark
Processor lithography	32 nm
Processor manufacturer	Intel
Thermal Design Power (TDP)	12.5 W
Memory bandwidth supported by processor (max)	2.5 GB/s
Memory bus	32 bit
Flash memory	8 MB
Memory channels	Single-channel
Flash memory type	Norwegian
Memory clock speed	800 MHz
Internal memory type	DDR3
Number of DIMM slots	0
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum internal memory	0.256 GB
Maximum memory card size	32 GB
SRAM (Static Random Access Memory)	512 KB
EEPROM (Electrically Erasable Programmable Read-Only Memory)	8 KB
USB version	2.0
Ethernet LAN	Yes
USB ports quantity	3
Ethernet interface type	Fast Ethernet
ARK ID	78919
Status	Discontinued
Launch date	Q4'13
Package size	15 x 15 mm
FSBs supported	NA
Processor included	Intel® Quark™ SoC X1000 (16K Cache, 400 MHz)
Supported memory types	DDR3-SDRAM
Power over Ethernet (PoE) voltage	12 V
Export Control Classification Number (ECCN)	4A994
PCI Support	PCI Express
PCI Express interface data lanes	x1
Form factor	Arduino
Market segment	Desktop
DC input voltage	5 V
Intel Small Business Advantage (SBA) version	0.00
Last change	63903513
Processor ID	79084
Product type	11
Harmonized System (HS) code	8471500150

Weight and Dimensions

Width	- mm
