Ring Wake-up
The optional settings: [Disabled]; [Enabled].
*Note: This function is supported when ‘ERP Support’ is set as [Disabled].
► Super I/O Configuration
Press [Enter] to make settings for the following sub-items:
Super IO Configuration
ERP Support
The optional settings: [Disabled]; [Auto].
This item should be set as [Disabled] if you wish to have all active wake-up
functions.
► Serial Port 1 Configuration
Press [Enter] to make settings for the following items:
Serial Port
Use this item to enable or disable Serial Port (COM).
The optional settings: [Disabled]; [Enabled].
When set as [Enabled], user can make further settings in the following items:
Device Settings
Change Settings
Use this item to select an optimal setting for Super IO Device.
The optional settings: [IO=3F8h; IRQ=4;]; [IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;];
[IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;]; [IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;];
[IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;].
Transmission Mode Select
The optional settings: [RS422]; [RS232]; [RS485].
Mode Speed Select
Use this item to select RS232/RS422/RS485 Speed.
The optional settings: [RS232/RS422/RS485=250Kbps]; [RS232=1Mbps,
RS422/RS485=10Mbps].
Serial Port FIF0 Mode
The optional settings: [16-Byte FIFO]; [32-Byte FIFO]; [64-Byte FIFO]; [128-Byte
FIFO].
To Next Page
