Intel H310 User Manual

8
Connectors
P/N Name
DCIN
19V DC-IN Power Jack
USB1/USB2
(For NF893-H310)
USB 3.1 (Gen.1) Port Connector X4
USB1/USB2
(For NF893-H370)
USB 3.1 (Gen.2) Port Connector X4
DP Display Port Connector
HDMI HDMI Port Connector
LAN RJ-45 LAN Connector
FP_HP Audio Line-out Connector
FP_MIC Audio MIC Connector
ATX2P Internal 19V Power Connector
SYSFAN System Fan Connector
CPUFAN CPUFAN Connector
SATA1/SATA2 SATAIII Connector X 2
SATAPWR SATA Power-out Connector
SPEAK_CON 3W Amplifier Connector
MON_SW Monitor Switch Connector
LVDS LVDS Port Connector
EDP(Optional) EDP Port Connector
INVERTER Flat Panel Backlight Inverter
Headers & Wafer
P/N Name Description
JW_FP
Front Panel Header(PWR LED/ HD
LED/Power Button /Reset)
9-pin Block
PS2KBMS PS2 Keyboard & Mouse Header 6-pin Block
COM Serial Port Header 9-pin Block
GPIO GPIO Port Header 10-pin Block
FP_USB3
(For NF893-H370)
USB 3.1 (Gen.2) Port Header 19-pin Block
FP_USB1/ FP_USB2 USB 2.0 Port Header 9-pin Block
FP_AUDIO Front Panel Audio Header 9-pin Block

Intel H310 Specifications

General

Chipset	Intel H310
Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
PCI Express Revision	3.0
SATA Ports	4
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCIe Lanes	6
RAID Support	No
Form Factor	ATX, Micro-ATX, Mini-ITX
USB 3.1 Gen 1 Ports	Up to 4
USB 2.0 Ports	Up to 6
M.2 Slots	1
Integrated Graphics	Yes (CPU Dependent)
LAN Speed	1 Gbps
USB Ports	Up to 10 (depends on implementation)
