Intel H310 User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
l Intel
®
H310/H370 express chipset
l LGA 1151 CPU socket supports Intel
®
Coffee Lake-S series processor (TDP ≤65
W).
l Support 2* DDR4 2400MHz SO-DIMM up to 32GB and dual channel function
l Support 1 * Intel i219-V Gigabit Ethernet LAN chip
l Support USB 3.1 data transport demand
l Support 2 * SATAIII (6Gb/s) ports
l Support 1* PCIE x1 slot, 1* M.2 E-key 2230 PCIe slot and 1* M.2 M-key
2242/2260/2280 slot
l Support 1 * HDMI + 1 * DP + 1* LVDS (option with eDP)
l Support 1 * COM, optional 4/6 * USB 3.1 & 4 * USB 2.0 for rich IO expansion
l Support Smart FAN function
l Supports ACPI S3 Function
l Compliance with ErP Standard
l Support Watchdog Timer Technology

Intel H310 Specifications

General

Chipset	Intel H310
Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
PCI Express Revision	3.0
SATA Ports	4
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCIe Lanes	6
RAID Support	No
Form Factor	ATX, Micro-ATX, Mini-ITX
USB 3.1 Gen 1 Ports	Up to 4
USB 2.0 Ports	Up to 6
M.2 Slots	1
Integrated Graphics	Yes (CPU Dependent)
LAN Speed	1 Gbps
USB Ports	Up to 10 (depends on implementation)
