1-2 Specification
Spec
Description
Design
l Thin mini-ITX form factor; PCB size: 17.0x17.0cm
Chipset
l Intel H310/H370 Express Chipset
CPU Socket
l Intel
®
LGA 1151 Socket for Coffee Lake-S series processors
*Note: for detailed CPU support information please visit our website
Memory Slot
l
2*
DDR
4
SO
-
DIMM slot
l Support DDR4 2400/2666 MHz SO-DIMM up to 32GB
l Support dual channel function
Expansion Slot
l
1* PCIE x1
slot (
P
CI
-
E
)
l 1* M.2 PCIE slot (
M2E
,2230 E-key PCIE interface)
Storage
l
2
* SATAIII 6G/s port
(SATA
1
/2
)
l 1* M.2 M-key slot, type-2242/2260/2280 with SATA interface (
M2M
,
*SATA/PCIE interface)
*Note: PCIE signal is supported by NF893-H370 series only.
LAN Chip
l Integrated with 1* Intel i219-V Gigabit PCI-E LAN chip
l Support Fast Ethernet LAN function of providing 10/100/1000Mbps
Ethernet data transfer rate
Audio Chip
l Realtek ALC662-VD 4-channel Audio Codec integrated
l Audio driver and utility included
BIOS l AMI Flash ROM
Multi I/O
Rear Panel I/O:
l 1*19V DC-in Power Jack
l
4* USB 3.1 (Gen.1) port (Optional for NF893-H310 Series)
l
4* USB 3.1 (Gen.2) port (Optional for NF893-H370 Series)
l 1* HDMI port
l 1* DP port
l 1* RJ-45 LAN port
l 1* Line-out port
l 1* MIC port
Internal I/O Connectors & Headers:
l 1 *2-pin 19V internal power connector
l 1* CPUFAN connector & 1* SYSFAN connector
l 1* SATA Power-out connector
l 1* MON_SW connector

Intel H310 Specifications

General

Chipset	Intel H310
Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
PCI Express Revision	3.0
SATA Ports	4
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCIe Lanes	6
RAID Support	No
Form Factor	ATX, Micro-ATX, Mini-ITX
USB 3.1 Gen 1 Ports	Up to 4
USB 2.0 Ports	Up to 6
M.2 Slots	1
Integrated Graphics	Yes (CPU Dependent)
LAN Speed	1 Gbps
USB Ports	Up to 10 (depends on implementation)
