(7) FP_AUDIO (9-pin): Line-Out, MIC-In Header
This header connects to Front Panel Line-out, MIC-In connector with cable.
Pin
1
GND
DETECT
MIC_JD
2
MIC2_L
LINE_OUT2_R
SENSE
LINE_OUT2_L
LINE_OUT2_JD
MIC2_R
(8) DMIC_CON (4-Pin): Digital Microphone Header
DMIC
_
DATA
Pin 1
VCC3
GND
DMIC
_
CLK
FP_
AUDIO
DMIC_CON
