Intel MAX 10 FPGA User Manual

1.2 Summary of MAX 10 Device Features
Table 2. Summary of Features for MAX 10 Devices
Feature Description
Technology 55 nm TSMC Embedded Flash (Flash + SRAM) process technology
Packaging • Low cost, small form factor packages—support multiple packaging
technologies and pin pitches
• Multiple device densities with compatible package footprints for seamless
migration between different device densities
• RoHS6-compliant
Core architecture • 4-input look-up table (LUT) and single register logic element (LE)
• LEs arranged in logic array block (LAB)
• Embedded RAM and user flash memory
• Clocks and PLLs
• Embedded multiplier blocks
• General purpose I/Os
Internal memory blocks • M9K—9 kilobits (Kb) memory blocks
• Cascadable blocks to create RAM, dual port, and FIFO functions
User flash memory (UFM) • User accessible non-volatile storage
• High speed operating frequency
• Large memory size
• High data retention
• Multiple interface option
Embedded multiplier blocks • One 18 × 18 or two 9 × 9 multiplier modes
• Cascadable blocks enabling creation of filters, arithmetic functions, and image
processing pipelines
ADC • 12-bit successive approximation register (SAR) type
• Up to 17 analog inputs
• Cumulative speed up to 1 million samples per second ( MSPS)
• Integrated temperature sensing capability
Clock networks • Global clocks support
• High speed frequency in clock network
Internal oscillator Built-in internal ring oscillator
PLLs • Analog-based
• Low jitter
• High precision clock synthesis
• Clock delay compensation
• Zero delay buffering
• Multiple output taps
General-purpose I/Os (GPIOs) • Multiple I/O standards support
• On-chip termination (OCT)
• Up to 830 megabits per second (Mbps) LVDS receiver, 800 Mbps LVDS
transmitter
External memory interface (EMIF)
1
Supports up to 600 Mbps external memory interfaces:
continued...
1 EMIF is only supported in selected MAX 10 device density and package combinations. Refer to
the External Memory Interface User Guide for more information.
1 MAX
®
10 FPGA Device Overview
