7. Boundary-Scan Description Language Support
The BSDL—a subset of VHDL—provides a syntax that allows you to describe the
features of an IEEE Std. 1149.1 BST-capable device that can be tested. Test software
development systems then use the BSDL files for test generation, analysis, failure
diagnostics, and in-system programming.
Related Information
IEEE 1149.1 BSDL Files
Provides more information about BSC group definitions.
