3. BST Operation Control
Table 3. Boundary-Scan Register Length for Intel MAX 10 Devices
Device Boundary-Scan Register Length
10M01 603
10M02 603
10M04 1080
10M08 732
10M16 1632
10M25 1164
10M40 1314
10M50 1620
Table 4. IDCODE Information for 32-Bit Intel MAX 10 Devices
The MSB is on the left. The IDCODE LSB is always 1.
Device
IDCODE (32 Bits)
Version (4 Bits) Part Number (16 Bits) Manufacturer Identity (11
Bits)
LSB (1 Bit)
10M01 0000 0010 0000 1111 0001 000 0110 1110 1
10M02 0000 0010 0000 1111 0001 000 0110 1110 1
10M04 0000 0010 0000 1111 0010 000 0110 1110 1
10M08 0000 0010 0000 1111 0011 000 0110 1110 1
10M16 0000 0010 0000 1111 0100 000 0110 1110 1
10M25 0000 0010 0000 1111 0101 000 0110 1110 1
10M40 0000 0010 0000 1111 0110 000 0110 1110 1
10M50 0000 0010 0000 1111 0111 000 0110 1110 1
3.1. JTAG IDCODE
The IDCODE is unique for each Intel MAX 10 device. Use this code to identify the
devices in a JTAG chain.
UG-M10JTAG | 2019.05.10
Send Feedback
