Table 5. IDCODE Information for Intel MAX 10 Devices
Supply Option
Device Device
Version (4
Bits)
Part Number (16 Bits) Manufacturer Identity
(11 Bits)
LSB (1
Bit)
Single-supply 10M02
(All except
U324)
0000 0011 0001 1000 0001 000 0110 1110 1
10M02
(U324)
0000 0011 0001 1001 1010 000 0110 1110 1
10M04 0000 0011 0001 1000 1010 000 0110 1110 1
10M08 0000 0011 0001 1000 0010 000 0110 1110 1
10M16 0000 0011 0001 1000 0011 000 0110 1110 1
10M25 0000 0011 0001 1000 0100 000 0110 1110 1
10M40 0000 0011 0001 1000 1101 000 0110 1110 1
10M50 0000 0011 0001 1000 0101 000 0110 1110 1
Dual-supply 10M02 0000 0011 0001 0000 0001 000 0110 1110 1
10M04 0000 0011 0001 0000 1010 000 0110 1110 1
10M08 0000 0011 0001 0000 0010 000 0110 1110 1
10M16 0000 0011 0001 0000 0011 000 0110 1110 1
10M25 0000 0011 0001 0000 0100 000 0110 1110 1
10M40 0000 0011 0001 0000 1101 000 0110 1110 1
10M50 0000 0011 0001 0000 0101 000 0110 1110 1
3.2. JTAG Secure Mode
In JTAG secure mode, the device only allows SAMPLE/PRELOAD, BYPASS, EXTEST,
and IDCODE JTAG instructions.
Related Information
MAX 10 FPGA Configuration User Guide
Provides more information about the JTAG Secure Mode.
3.3. JTAG Private Instruction
Caution: Never invoke the following instruction codes. These instructions can damage the
device and render it unusable:
• 10 0100 0000
• 10 0011 0000
• 10 1110 0000
• 10 0011 0001
3. BST Operation Control
UG-M10JTAG | 2019.05.10
Intel
®
MAX
®
10 JTAG Boundary-Scan Testing User Guide
Send Feedback
8
