Intel S1200BTLRM Specification

BIOS User Interface Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
88
Error Manager
Exit
ERROR CODE SEVERITY INSTANCE
Figure 43. Error Manager Screen
6.5.2.28 System Event Log Screen (Tab)
The System Event Log screen appears only for server boards (other than Compute Module
boards) which do not have an onboard Baseboard Management Controller. These boards
maintain the System Event Log internally by using the SMBIOS Type 15 mechanism.
The System Event Log viewer can display as many log records as are stored in a single page.
Each Event Record is displayed on one line. The most recent Event Record is displayed on the
top. When there are more Event Records that can be displayed at once, the <PageUp> and
<PageDown> keys can be used. There is also a scroll bar to allow users to view the logs from
beginning to the end.
Note: When the System Event Log is full, or when the user wishes to remove the current Event
Records, the user can choose Clear System Event Log in Setup.
System Event Log
No. Event Info Time
005 M-BIT MEM ECC Error CPU0 Ch 0 Dimm0 10/15/09 15:12:23
004 S-BIT MEM ECC Error CPU0 Ch 0 Dimm0 10/15/09 15:11:25
003 PCIE UNCOR ERR Bus0 Dev 1C Fun0 10/15/09 15:08:36
002 MEM Parity Error CPU0 Ch 0 Dimm0 10/15/09 15:07:11
001 Thermal Trip Occurred. 10/15/09 15:05:05
Figure 44. System Event Log Screen (S1200BTS)
