Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
42
2U 2.5” Front Mount Drive Configurations – SAS Data Cable Guide (with no SAS Expander)
Table 7. 2U 8 x 2.5" (Drive Bay #1) - SAS/SATA Data Cable Guid (with no SAS Expander)
System
Configuration
Drive Support
Drive Bay #1
R2208…
R2216…
R2224…
8 x 2.5”
SATA Cntlr -> BP 0-3
730mm HD --- HD
sSATA Cntrl -> BP 4-7
730 mm HD --- HD
From data above, select
appropriate cable kits
from list below:
AXXCBL730HDHD
(2) 730mm Cables
included with all 2.5” L6
Integrated systems
SAS Mezz -> BP 0-3
730 mm HD --- HD
SAS Mezz -> BP 4-7
730 mm HD --- HD
From data above, select
appropriate cable kits from
list below:
AXXCBL730HDHD
(2) 730mm Cables
included with all 2.5” L6
Integrated systems
SAS Mezz -> BP 0-3
730 mm HD --- MS
SAS Mezz -> BP 4-7
730 mm HD --- MS
From data above, select
appropriate cable kits from
list below:
AXXCBL730HDMS
Cable Connections:
SAS PCIe -> BP 0-3
730 mm HD --- HD
SAS PCIe -> BP 4-7
730 mm HD --- HD
From Riser #2
SAS PCIe -> BP 0-3
730 mm HD --- HD
SAS PCIe -> BP 4-7
730 mm HD --- HD
From data above, select
appropriate cable kits
from list below:
AXXCBL730HDHD
(2) 730mm Cables
included with all 2.5” L6
Cable Connections:
SAS PCIe -> BP 0-3
730 mm HD --- MS
SAS PCIe -> BP 4-7
730 mm HD --- MS
From Riser #2
SAS PCIe -> BP 0-3
730 mm HD --- MS
SAS PCIe -> BP 4-7
730 mm HD --- MS
From data above, select
appropriate cable kits
from list below:
AXXCBL730HDMS
** 1 or 2 cable lengths may be specified for a PCIe add-in card. Generally, if the cable connector of the add-in card is located on the back edge of the card, a
shorter cable is specified. Cable connectors on the top edge or near the front of the add-in card will require the longer cable length.
