Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
70
Intel Product Code
Order Information Product Description
Product Type
iPC – AXX1P40FRTIOM
iPC – AXX2P40FRTIOM
MM# – 933742
UPC – 00735858282291
EAN –
5032037063623
MOQ – 1
MM# – 933743
UPC –
00735858282314
EAN – 5032037063647
MOQ – 1
Intel® I/O Modules
AXX1P40FRTIOM
&
AXX2P40FRTIOM
Intel
®
Single and Dual-Port 40G QSFP+ Ethernet I/O Moduless based on XL710-AM2 10
Gigabit Ethernet Controller
On the dual port module, the 4x10GbE SFP+ break out is supported on Port 0 only
Available Optics Accessories:
Intel
®
Ethernet QSFP+ SR4 Optics, E40GQSFPSR
Intel
®
Ethernet 40G DCO Optics, E40GDCOQSFP
Connector and cables:
40GBASE-CR4, QSFP+ Direct Attached Copper Cable
Intel
®
Ethernet QSFP+ SR4 Optics also supported
Intel
®
Ethernet 40G DCO Optics, E40GDCOQSFP
Cabling type:
10GBASE-CR4: Copper Direct Attach passive cable (1–7m);
10GBASE-SR4: MMF (OM3) up to 100m
Intel
®
Ethernet 40G DCO Optics up to 50m
Kits Include:
(1) I/O module
(1) EMI shield
(1) Port Labeling Sticker (2 Port only model)
(1 set) Mounting screws
• 1U / 2U
Accessory Kit
iPC – AXX10GBNIAIOM
MM# – 917905
UPC –
00735858241090
EAN –
5032037035842
MOQ – 1
Intel® I/O Module
AXX10GBNIAIOM
Dual SFP+ port 10GbE IO module based on Intel
®
82599ES 10 Gigabit
Ethernet Controller
Kit Includes:
(1) I/O module
(1) EMI shield
(1) Port Labeling Sticker
(1 set) Mounting screws
• 1U / 2U
Accessory Kit
