Server Board S5500BC User’s Guide
Table 1 summarizes the features of the server board.
Table 1. Intel
®
Server Board S5500BC Feature Summary
Feature Description
Processors Supports up to two Intel
®
Xeon
®
5500 series processors with Intel
®
QuickPath Interconnect and Integrated Memory controllers.
Memory • Eight DDR3 DIMM slots supporting
DDR3 800/1066/1333 MT/s ECC Registered DIMM and ECC
or Non-ECC unbuffered DIMM.
• Four slots support CPU_1 and four slots support CPU_2.
Chipset
• Intel
®
I/O Hub (IOH) 5500 chipset
• Intel
®
82801 Jx I/O Controller Hub 10 RAID (ICH10R)
I/O Control ServerEngines* LLC Pilot II BMC controller (Integrated BMC)
Peripheral Interfaces
• Three x8 PCI Express* Gen2 connectors
• One x4 PCI Express* Gen1 connector
• One 5 V 32-bit/33 MHz PCI connector
• Two stacked RJ-45 connectors with Magnetics and LEDs and
two USB combo connectors
• One external Serial Port Header (9 pin)
• Optional Intel
®
Remote Management Module 3
LAN Two 10/100/1000 NICs
• One Gigabit Ethernet device (82574L) connects to the PCI
Express* Gen2 x1 interface on the Intel
®
IOH 5500 chipset.
• One Gigabit Ethernet device (82567) connects to the Gigabit
LAN Connect Interface / LAN Connect Interface on the Intel
®
ICH10R.
Expansion Capabilities One riser slot supporting one low-profile half-length PCI Express*
2.0 x8 add-in card.
Fans Supports two processor fan connectors and three system fan
connectors
BIOS EFI BIOS
Server Management Intel
®
System Management Software
