16
Intel
®
Server Board S5500BC User’s Guide
Figure 9. Open the Load Plate
7.
Remove the socket
protective cover (see Figure
10).
Figure 10. Remove the Socket Protective Cove
r
8.
T
ake the processor out of the b
ox and remove the protect
ive shipping cover
(Figure
1
1).
Figure 11. Remove the Proce
ssor Protective Cover
