Platform Management Intel® Server Board SE7520JR2
Revision 1.0
C78844-002
114
Element
On-Board
Platform
Instrumentation
Intel®
Management
Module -
Professional
Edition
Intel®
Management
Module -
Advanced
Edition
IPMI Channels, and Sessions Limited Yes Yes
EMP (Emergency Management Port) - IPMI Messaging over
Serial/Modem. This feature is also referred to as DPC (Direct
Platform Control) over serial/modem. No Yes Yes
Serial/Modem Paging No Yes Yes
Serial/Modem Alerting over PPP using the Platform Event Trap
(PET) format No Yes Yes
DPC (Direct Platform Control) - IPMI Messaging over LAN
(available via both on-board network controllers) Yes Yes Yes
LAN Alerting using PET Yes Yes Yes
Platform Event Filtering (PEF) Yes Yes Yes
ICMB (Intelligent Chassis Management Bus) - IPMI Messaging
between chassis No Yes Yes
PCI SMBus support No Yes Yes
Fault Resilient Booting Limited Yes Yes
BIOS logging of POST progress and POST errors Errors Only Yes Yes
Integration with BIOS console redirection via IPMI v2.0 Serial
Port Sharing No Yes Yes
Access via web browser No No Yes
SNMP access No No Yes
Telnet access No No Yes
DNS support No No Yes
DHCP support (dedicated NIC only) No No Yes
Memory Sparing/Mirroring sensor support No Yes Yes
Alerting via Email No No Yes
Keyboard, Video, Mouse (KVM) redirection via LAN No No Yes
High speed access to dedicated NIC No No Yes
This chapter will provide an overview of the On-board Platform Instrumentation architecture and
details of it features and functionality including BIOS interactions and support. Refer to the
Technical Product Specification for the Professional and Advanced modules for detailed
description of their features and functionality.
Note: The generic term “BMC” may be used throughout this section when a feature and/or
function being described is common to both the mBMC and the Sahalee BMC. If a described
feature or function is unique, the specific management controller will be referenced.
