Intel® Server Board SE7520JR2 Introduction
Revision 1.0
C78844-002
19
1. Introduction
This Technical Product Specification (TPS) provides detail to the architecture and feature set of
the Intel
®
Server Board SE7520JR2.
The target audience for this document is anyone wishing to obtain more in depth detail of the
server board than what is generally made available in the board’s Users Guide. It is a technical
document meant to assist people with understanding and learning more about the specific
features of the board.
This is one of several technical documents available for this server board. All of the functional
sub-systems that make up the board are described in this document. However, some low-level
detail of specific sub-systems is not included. Design level information for specific sub-systems
can be obtained by ordering the External Product Specification (EPS) for a given sub-system.
The EPS documents available for this server board include the following:
• Intel
®
Server Board SE7520JR2 BIOS EPS
• Intel
®
Server Board SE7520JR2 Baseboard Management Controller EPS
• mini Baseboard Management Controller (mBMC) Core EPS for IPMI-based Systems
• Sahalee Core BMC EPS for IPMI v1.5
These documents are not publicly available and must be ordered by your local Intel
representative.
1.1 Chapter Outline
This document is divided into the following chapters
• Chapter 1 – Introduction
• Chapter 2 – Product Overview
• Chapter 3 – Board Architecture
• Chapter 4 – System BIOS
• Chapter 5 – Platform Management Architecture
• Chapter 6 – Error Reporting and Handling
• Chapter 7 – Connector Pin-out and Jumper Blocks
• Chapter 8 – Environmental Specifications
• Chapter 9 – Miscellaneous Board Information
• Appendix A – Integration and Usage Tips
