Platform Management Intel® Server Board SE7520JR2
Revision 1.0
C78844-002
134
5.3.16 mBMC Self Test
The mBMC performs various tests as part of its initialization. If a failure is determined (e.g.,
corrupt mBMC FRU, SDR, or SEL), the mBMC stores the error internally.
5.3.17 Messaging Interfaces
This section describes the supported mBMC communication interfaces:
• Host SMS Interface via SMBus interface
• LAN interface using the LOM SMBus
These specifications are defined in the following subsections.
5.3.17.1 Channel Management
The mBMC supports two channels:
• System interface
• 802.3 LAN
Table 52: Suported Channel Assignments
Channel ID Media Type Interface Supports Sessions
1 802.3 LAN IPMB 1.0 Multi-sessions
2 System Interface IPMI-SMBus Session-less
5.3.17.2 User Model
The mBMC supports one anonymous user (null user name) with a settable password. The IPMI
Set User Password command is supported.
5.3.17.3 Request/Response Protocol
All of the protocols used in the above mentioned interfaces are Request/Response protocols. A
Request Message is issued to an intelligent device, to which the device responds with a
Response Message.
As an example, with respect to the IPMB interface, both Request Messages and Response
Messages are transmitted on the bus using SMBus Master Write transfers. In other words, a
Request Message is issued from an intelligent device acting as an SMBus master, and is
received by an intelligent device as an SMBus slave. The corresponding Response Message is
issued from the responding intelligent device as an SMBus master, and is received by the
request originator as an SMBus slave.
5.3.17.4 Host to mBMC Communication Interface
The host communicates with the mBMC via the System Management Bus (SMBus). The
interface consists of three signals:
• SMBus clock signal (SCLH)
