Intel SE7520JR2 Technical Manual

Intel® Server Board SE7520JR2 Functional Architecture
Revision 1.0
C78844-002
51
Table 8: PCI Configuration IDs and Device Numbers
PCI Device IDSEL Bus# / Device# / Function#
MCH host-HI bridge/DRAM controller 00 / 00 / 0
MCH DRAM Controller Error Reporting 00/00/1
MCH DMA controller 00/01/00
MCH EXP Bridge A0 00/02/00
MCH EXP Bridge A1 00/03/00
MCH EXP Bridge B0 00/04/00
MCH EXP Bridge B1 00/05/00
MCH EXP Bridge C0 00/06/00
MCH EXP Bridge C1 00/07/00
MCH Extended Configuration 00/08/00
ICH5R Hub interface to PCI bridge 00 / 30 / 00
ICH5R PCI to LPC interface 00 / 31 / 00
ICH5R IDE controller 00 / 31 / 01
ICH5R Serial ATA 00 / 31 / 02
ICH5R SMBus controller 00 / 31 / 03
ICH5R USB UHCI controller #1 00 / 29 / 00
ICH5R USB UHCI controller #2 00 / 29 / 01
ICH5R USB UHCI controller #3 00 / 29 / 02
ICH5R USB 2.0 EHCI controller 00 / 29 / 07
FL Slot1 (64-bit, PCIX-100) P1A_AD17 / 01 /
FL Slot2(64-bit, PCI-X-100) P1A_AD18 / 02 /
FL Slot3 (64-bit, PCI-X-100) P1A_AD19 / 03 /
FL PXH Slot1 P2A_AD17 /01/
FL PXH Slot 2 P2B_AD17 /01/
FL PCI-E x8 Slot1 /00/
FL PCI-E x4 Slot1 /00/
FL PCI-E x4 Slot2 /00/
LP Slot1 (64-bit, PCI-X-100) P1B_AD17 / 01 /
LP Slot2 (64-bit, PCI-X-100) P1B_AD18 / 02 /
LF Slot3 (64-bit, PCI-X-100) P1B_AD19 / 03 /
On board device
Intel 82546GB(1Gb) NIC w/ dual channel P1B_AD20 / 04 /0,1
LSI53C1030 Ultra 320 SCSI w/ dual
channel
P1A_AD21 /05/0,1
ATI Rage XL (PCI VGA) PC_AD28 / 12 /0
Note: Bus Numbers may change depending on the type of riser card used.
