Intel SE7520JR2 Technical Manual

System BIOS Intel® Server Board SE7520JR2
Revision 1.0
C78844-002
90
Table 24: BIOS Setup, IDE Device Configuration Sub-menu Selections
Feature Options Help Text Description
Primary/Secondary/Third/Fourth IDE Master/Slave
Device N/A N/A Display detected device info
Vendor N/A N/A. Display IDE device vendor.
Size N/A N/A Display IDE DISK size.
LBA Mode N/A N/A Display LBA Mode
Block Mode N/A N/A Display Block Mode
PIO Mode N/A N/A Display PIO Mode
Async DMA N/A N/A Display Async DMA mode
Ultra DMA N/A N/A Display Ultra DMA mode.
S.M.A.R.T. N/A N/A Display S.M.A.R.T. support.
Type Not Installed
Auto
CDROM
ARMD
Select the type of device connected
to the system.
The Auto setting should work in
most cases.
LBA/Large Mode Disabled
Auto
Disabled: Disables LBA Mode.
Auto: Enabled LBA Mode if the
device supports it and the device is
not already formatted with LBA
Mode disabled.
The Auto setting should work in
most cases.
Block (Multi-Sector
Transfer) Mode
Disabled
Auto
Disabled: The Data transfer from
and to the device occurs one sector
at a time.
Auto: The data transfer from and to
the device occurs multiple sectors at
a time if the device supports it.
The Auto setting should work in
most cases.
PIO Mode
Auto
0
1
2
3
4
Select PIO Mode. The Auto setting should work in
most cases.
DMA Mode
Auto
SWDMA0-0
SWDMA0-1
SWDMA0-2
MWDMA0-0
MWDMA0-1
MWDMA0-2
UWDMA0-0
UWDMA0-1
UWDMA0-2
UWDMA0-3
UWDMA0-4
UWDMA0-5
Select DMA Mode.
Auto :Auto detected
SWDMA :SinglewordDMAn
MWDMA :MultiwordDMAn
UWDMA :UltraDMAn
The Auto setting should work in
most cases.
S.M.A.R.T.
Auto
Disabled
Enabled
Self-Monitoring, Analysis and
Reporting Technology.
The Auto setting should work in
most cases.
32Bit Data Transfer
Disabled
Enabled
Enable/Disable 32-bit Data Transfer
