Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA 5
Remove PCI Riser Assembly
8. Unlatch the two levers (see letter “A” in the following figure) on the PCI riser
assembly and lift the assembly out of the chassis (see letter “B”). Lay the PCI riser
assembly over on its side (see letter “C”). Be sure to support the PCI riser assembly so
that the connectors on the PCI riser assembly and components on the PCI RAID
controller card(s) are not rubbing against the sheet metal of the chassis.
Figure 4. Removing PCI Riser Assembly from Chassis
TP00879
B
A
A
C
