Intel SSR212MA Install Guide

Disk on Module (DOM) Install Guide
Disk on Module (DOM) Install Guide: Intel® Storage System SSR212MA 11
Close Enclosure Cover
15. Align the enclosure cover over the corresponding notches in the chassis (see letter
“A” in the following figure). Slide the enclosure cover toward the front of the chassis
(see letter “B”). With a screwdriver, secure the enclosure cover to the chassis by
turning the lock (see letter “C”) a quarter turn until the lock symbol aligns with the
notch on the cover.
Figure 11. Closing Enclosure Cover
Complete Setup
16. Re-connect all peripheral devices and the AC power cable. Power up the storage
system.
17. Refer to the Intel® Storage System Software User Manual for information on
activating the DOM and updating the software.
TP01847
A
B
C
