Motherboard Description
29
1.11.10.1 Serial Port Connectors (J1J1, J1K1)
Pin Signal Name
1 DCD
2 Serial In #
3 Serial Out #
4 DTR#
5 Ground
6 DSR#
7 RTS#
8 CTS#
9 Ground
1.11.10.2 PS/2 Keyboard and Mouse Connectors (J1M1)
Pin Signal Name
1 Data
2 No connect
3 Ground
4 +5 V (fused)
5 Clock
6 No connect
1.11.10.3 Parallel Port Connector (J1J2)
Pin Signal Name
Pin
Signal Name
1 Strobe#
14
Auto Feed#
2 Data bit 0
15
Fault#
3 Data bit 1
16
INIT#
4 Data bit 2
17
SLCT IN#
5 Data bit 3
18
Ground
6 Data bit 4
19
Ground
7 Data bit 5
20
Ground
8 Data bit 6
21
Ground
9 Data bit 7
22
Ground
10 ACK#
23
Ground
11 Busy
24
Ground
12 Error
25
Ground
13 Select
