VS440FX Motherboard Technical Product Specification
30
1.11.10.4 USB Connectors (J1L1)
Pin Signal Name
1 Power
2 USBP0# [USBP1#]
3 USBP0 [USBP1]
4 Ground
1.11.10.5 MIDI/Game Port (J1G1)
Pin Signal Name
1 Vcc
2 JBUT0
3 JSX1
4 Ground
5 Ground
6 JSY1
7 JBUT1
8 Vcc
9 Vcc
10 JBUT2
11 JSX2
12 MIDI-OUT
13 JSY2
14 JBUT3
15 MIDI-IN
