Intelligent lighting DMX-240A, DMX-240B User Manual

DMX 512 CONTROLLER SERIES
4.4 Technical Specifications
Weight........................................................................................................................... 3.5 Kg
Operating Range.....................................................................................DC 9V-12V 500mA min
Maximum ambient temperature.......................................................................................45 C
Data input .................................................................................. locking 3-pin XLR male socket
Data output ............................................................................. locking 3-pin XLR female socket
Data pin configuration ..................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols........................................................................................................DMX-512 USITT
Protocols........................................................................................................DMX-512 USITT
DMX-240A USER MANUAL
20/20

Intelligent lighting DMX-240A, DMX-240B Specifications

Power

operating range voltage	9V-12V
operating range current	500mA

Operating Environment

maximum ambient temperature	45 C

Ports & interfaces

data input	locking 3-pin XLR male socket
data output	locking 3-pin XLR female socket
data pin configuration	pin 1 shield, pin 2 (-), pin 3 (+)

Weight and Dimensions

weight	3.5 Kg
