Intelligent lighting DMX-240A, DMX-240B User Manual

DMX 512 CONTROLLER SERIES
Item
30
31
35
37
38
33
32
36
34
Button or Fader
Audio input jack
MIDI input port
Fog machine socket
USB Lamp socket
DMX output connector
DMX polarity switch
DC Input jack
DMX input connector
Function
Direct audio feed for use in sound-active mode
For external triggering of Banks and Chases using a
MIDI device
May be used to correct signal polarity
Used to transfer programmed data between 2 controllers
ON/OFF power switch
2.4 Product Overview (rear panel)2.4 Product Overview (rear panel)
1=Ground
3=Data +
1
2
3
1
2
3
OFF
ON
POWER
DC 9V-12V
300mA min
MACHINE
DC INPUT
FOG
DMX IN
DMX OUT
DMX OUT
MIDI
LAMP
USB
0.1-1VP-P
AUDIO
DMX Polarity select
1
2
3
1=Ground
2=Data +
30 31 32 33 34 35 36 37 38
DMX control signal
Main power feed
Turns the controller on and off
DMX-240A USER MANUAL
6/20

Intelligent lighting DMX-240A, DMX-240B Specifications

Power

operating range voltage	9V-12V
operating range current	500mA

Operating Environment

maximum ambient temperature	45 C

Ports & interfaces

data input	locking 3-pin XLR male socket
data output	locking 3-pin XLR female socket
data pin configuration	pin 1 shield, pin 2 (-), pin 3 (+)

Weight and Dimensions

weight	3.5 Kg
