DMX 512 CONTROLLER SERIES
2.INTRODUCTION2.INTRODUCTION
2.1 Features2.1 Features
* Universal DMX-512 Controller
* Controls 12 intelligent lights of up to 16 channels
* 30 banks of 8 scenes, 240 scenes total
* 6 sets of chases containing 240 scenes
* Execute multiple chases simultaneously
* Re-assignable channels
* wheel assignable Pan/Tilt and 16bit control
* Beat-activation, tap sync, auto run
* Grab any fixture on the fly
* Polarity selector
* Midi compatible
2.2 General Overview2.2 General Overview
* The DMX-240A is a universal intelligent lighting controller. It allows the control of
12 fixtures composed of 16 channels each and up to 240 programmable scenes.
Six chase banks can contain up to 240 steps composed of the saved scenes and
in any order. Programs can be triggered by music, midi,automatically or manually.
Allchasescanbeexecutedatthesametime.
* On the surface you will find various programming tools such as 8 universal channel
sliders, a wheel and LED display indicators for easier navigation of controls and
menu functions. You can control the pan and tilt of different intelligent lighting fixtures
using the same wheel at the same time by means of a programmable wheel.
This wheel allows the user to assign individual pan and tilt channels for every fixture.
2.3 Product Overview (front)2.3 Product Overview (front)
1
2
3
4
5
6
7
8
9
10
11
12
PAG E A
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
DMX 512 CONTROLLER
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
0
2
4
6
8
10
10
8
6
4
2
0
0.1/SEC
30 SEC
30 SEC
10 MIN10 MIN 0SEC0 SEC
AUTO
DEL
MUSIC
BANK COPYBANK COPY
DMX-240A
INTELLIGENT LIGHTING
SPEED FADE TIME
1
2
20
4
5
6
7
8
9
10 11 1312 14 15
16
17
18
19
21
25
23
24
22
26
3
29
28
27
DMX-240A USER MANUAL
3/20
