DMX 512 CONTROLLER SERIES
3.1.2 FIXTURE ADDRESSING3.1.2 FIXTURE ADDRESSING
The DMX-240A is programmed to control 16 channels of DMX per fixture, therefore the fixtures you
wish to control with the corresponding buttons on the unit, must be spaced 16 channels
apart.
SCANNER
FIXTURE OR
SCANNER #
DEFAULT DMX STARTING
ADDRESS
BINARY DIPSWITCH SETTINGS
SWITCH TO THE ON POSITION
1
2
3
4
5
6
7
8
9
10
11
12
1
17
33
49
65
81
97
113
129
145
161
177
1
1,5
1,6
1,5,6
1,7
1,5,7
1,6,7
1,5,6,7
1,8
1,5,8
1,6,8
1,5,6,8
Please refer to your individual fixture s manual for DMX addressing instructions. The table above
refers to a standard 9 dipswitch binary configurable device.
3.1.3 WHEEL ASSIGNMENT3.1.3 WHEEL ASSIGNMENT
Because not all intelligent lighting fixtures are alike or share the same control attributes, the DMX-240A
allows the user to assign the wheel the correct pan and tilt channel for every individual fixture
including 16 bit channel assignments. It also allows the user to re-assign physical faders to fixture
DMX channels so that the user can combine or unify control of similar or the same attributes across
different types of fixtures.
Action :Action :
1) press and hold the button until
the led blinks
PROGRAM
2)
Press and hold & buttons together
(2) times to access the channel assignment mode.
the assign led will light. the wheel can be
reassigned to output on a different dmx channel.
FINE MODE
3) press a button that represents the fixture
you would like to set the pan&tilt
SCANNER
Notes :Notes :
All wheels can be reassigned to output on a
different DMX channel.
Press AUTO/DEL&MODE buttons together to
delete the channel assignment mode.
DMX-240A USER MANUAL
8/20
4) Use the buttons to select pan/tiltBANKUP/DOWN
