- 20 -
PLUxx
Select PLU from scale memory to be used
T
Tare current weight value
T123.456
preset tare value is 123.456
Z
Zero the display
P
Print using selected format
M+
Store current results into memory and print
MR
Recall memory values to scale display
MC
Clear memory
U123.456
Store unit weight of 123.456(grams if in kilograms or pounds if
currently in pounds)
S123
Enter sample size of 123 parts. Same as pressing Smpl key.
SL
Select local scale to be used
SR
Select remote scale to be used
Immediate Printing Commands:
Command
Output from scale
\L
Scale: Local or Remote
\I
ID number same as PUID below
\S
Scale number same as PSID below
\N
Net weight
\G
Gross Weight
\T
Tare weight
\U
Unit weight
\P
Count
\C
Total Count
\W
Total Weight
\M
Number of items stored in memory
\B
A blank line printed
9.2 STORING DATA VIA RS232
To store data the commands are:
SUIDxxxxxx <CR>
Store user ID data
SSIDxxxxxx <CR>
Store scale ID data
SPLUxx,xxxxxxxxxxxx <CR>
Store text data for PLUxx
When PLU text data is stored the Scale used, current unit weight and current tare
value is also stored to that PLU number.
For the SPLU command the data is: PLU number (2 characters), (Comma) description
(max 12 characters).
If the fields are less than the maximum all characters need not be used.
9.3 PLU ENTRY USING RS-232 INTERFACE
