Intelligent Weighing Technology Intell-Count IDC 3 User Manual

- 2 -
SECTION 2 TECHNICAL SPECIFICATIONS
2.1 SPECIFICATIONS FOR THE LOCAL SCALE
Model
IDC 3
IDC 6
IDC 15
IDC 30
Maximum Capacity
3000 g
6000 g
15 kg
30 kg
Readability
0.05 g
0.1 g
0.2 g
0.5 g
Tare Range
-3 kg
-6 kg
-10 kg
-30 kg
Repeatability(Std Dev)
0.1 g
0.1 g
0.2 g
0.5 g
Linearity ±
0.1 g
0.2 g
0.5 g
1 g
Units of Measure
lb, kg
2.2 SPECIFICATIONS FOR THE REMOTE SCALE
Excitation voltage
5 VDC
Signal range
0-20 mv(allows 3 mv/v LC with 5mv zero offset)
Zero range
0-5 mv
Sensitivity
0.02 µv/internal ADC count or better
Internal ADC counts
500,000 maximum at 10 mv input
Load
87 ohm minimum, 4 X 350 ohm load cells
Connection
4 wire connection to load cells plus shield
Maximum cable length
20 ft - 6 meters
Termination
DB 9 subminiature plug on scale
2.3 COMMON SPECIFICATIONS
Interface
Bi-directional RS-232 Interface
Stabilization Time
2 Seconds
Operating Temperature
0°C - 40°C (32°F - 104°F)
Power supply
9 VDC 800 mA from external power supply
Calibration
Automatic external
Display
3 x 6 digits LCD digital display
Housing Indicator
ABS Plastic, Stainless Steel pan
Pan size
225 x 300mm / 8.9 x 11.8”
Overall dimensions
320 x 340 x 125mm / 12.6 x 13.4 x 4.9”
Net weight
3.8kg / 8.4lb
Applications
Counting Scale
Functions
Weighing, parts counting, accumulating memory,
preset count with alarm, up to 100 PLUs with
description, unit & tare weight
Other Features and Specs
Accuracy enhancement for parts counting,
internal rechargeable battery (~70 hours operation)
