Intense m16 - Frame Features; Component Spec

Frame features //
• Adjustable travel – 8.5” or 9.5” (215mm or 241mm)
• adjustable shock curve progression
• 27.5" wheel size
• Patented VPP Suspension Technology
• Tapered Head Tube
• ISCG 05 Mounts
• Modern DH Race Geometry
• Integrated 157X12 dropouts
• External Cable Routing System
• Angular Contact Bearing / Collet 15MM Axle System with
replaceable Grease Zerks
• FLack GuaRD Chain stay & Down tube Protection
• Integrated fork bumper/cable guide system
Component spec //
• Fork – accepts 1.125" straight steer or 1.125"/1.5" tapered steer, 200mm Travel,
594mm lower leg length, 42mm offset
• Shock – 9.5” x 3”(241mm x 76mm), 22mm x 8mm and 34mm x 8mm reducers
• Chain Guide Mount - ISCG-05
• Seat post – 31.6mm
• Headset – zero stack 49 upper / 56 lower cups
• BOTTOM BRACKET - THREADED 83MM (M16)
• Rear Axle – 157mm x 12mm TA
• Brake Mount – international standard 160mm - 203mm rotor
4 // m16 user Manual
frame
features /
spec
