Intense m16 - Medium Large

INTENSE CYCLES // 7
ITEM PART NUMBER DESCRIPTION FRAME SIZE USED ON
Shock
370335 Shock CCDB-C M16, 240 x 76 x 350 Small
Shock
370336 Shock CCDB-C M16, 240 x 76 x 400 Medium
Shock
370337 Shock CCDB-C M16, 240 x 76 x 450 Large
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
1
Box Link 130214 Forged Lower Link 1 N/A
2
Top Link 130215 Forged Top Link 1 N/A
3
Cone Adjuster 130777 Expander Cone 3 N/A
4
Bearing Cap 130778 Main Pivot Bearing Cap 4 N/A
5
Axle Upper 130780 Top Link Pivot Axle 1
20 Nm /
175 in-lbs
6
Washer 130784 Top Link Pivot, Lower Washer 2 N/A
7
Bolt Shoulder 130785 Top Link Pivot Bolt 3
20 Nm /
175 in-lbs
8
Spacer 130789 Top Link Pivot, Upper Spacer 2 N/A
9
Hanger 130790 Forged Derailleur Hanger 1 N/A
10
Rear Axle 130794 157 x 12mm Axle 1
11 Nm /
100 in-lbs
11
Bolt Main
Pivot
130795 Main Pivot 1.5T Expander Bolt 2
7 Nm /
60 in-lbs
12
Hanger Bolt 130798 Rear Derailleur Hanger Bolt 1
11 Nm /
100 in-lbs
13
Plug 140004 Box Link Pivot Plug 2 N/A
14
Bumper 140009 Fork Bumper Left 1 N/A
15
Bumper 140010 Fork Bumper Right 1 N /A
16
Fender 140011 Rear Wheel Fender 1 N/A
17
Clip Plastic 310001 Snap-on Cable Guide Single 9 N/A
18
Seat Collar 346941 Bolt-on 36.1 1 N/A
19
M8 Nut 400005 Shock Bolt Nyloc Nut 1
16 Nm /
140 in-lbs
20
Zerk Fitting 401011 M6 x 1.0 2
5 Nm /
40 in-lbs
21
SHCS
M6 x 22
410009
Cone Adjuster Bolt, Socket Head,
M6 x 22
2
14 Nm /
125 in-lbs
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
22
BHCS
M5 X 12
410010
Guide Bolt, Button Head,
M5 X 12
4
6 Nm /
54 in-lbs
23
SHCS
M8 x 60
410012
Shock Bolt Socket Head,
M5 X 12
1
16 Nm /
140 in-lbs
24
SHCS
M8 x 35
410038
Shock Bolt, Socket Head,
M8 x 35
1
16 Nm /
140 in-lbs
25
SHCS
M6 x 25
410039
Cone Adjuster Bolt, Socket Head,
M6 x 25
1
14 Nm /
125 in-lbs
26
M8 Washer 420004 Shock Bolt Washer 2 N/A
27
Bearing 6901 430001 12 x 24 x 6 2RS Radial Bearing 2 N/A
28
Bearing 7902 430007
15 x 28 x 7 2RS
MAX Angular Contact Bearing
4 N/A
29
Bearing 6802 430008
15 x 24 x 5 2RS
MAX Radial Bearing
2 N/A
30
Guard Flack SS 500235 Flack Guard, M16 Seat Stay 1 N/A
31
Guard Flack
DT
500236 Flack Guard, M16 Down Tube 1 N/A
32
Guard Flack CS 500238 Flack Guard, M16 Chain Stay 1 N/A
33
Decal 500300 Decal California Bear 1 N/A
34
Head Badge 500337 M16 Head Badge 1 N/A
35
Front Triangle Aluminum, 3 sizes 1 N/A
36
Rear Triangle Aluminum, 1 Size 1 N/A
37
Rear Shock 240mm x 76mm 1 N/A
