Intense m16 - TORQUE SPECIFICATIONS; IMPORTANCE OF PROPER TORQUE

torque
Achieving proper torque is vital to
ensuring the safe performance and
function of the m16 frame. Failure
to do so could result in sub-optimal
performance of your frame as well as
premature wear and tear of individual
parts.
additional reference
In addition to this chart, all torque
values are laser etched onto
corresponding hardware for your
reference.
14 // m16 user Manual
torque chart
20 Nm / 175 in-lbs
16 Nm / 140 in-lbs
20 Nm / 175 in-lbs
16 Nm / 140 in-lbs
6 Nm / 54 in-lbs
M8 HEX 7 Nm / 60 in-lbs
M6 HEX 14 Nm / 125 in-lbs
M8 HEX 7 Nm / 60 in-lbs
M6 HEX 14 Nm / 125 in-lbs
Rear Axle 11 Nm / 100 in-lbs
M6 HEX 14 Nm / 125 in-lbs
