4 // sniper T manual
getting to
know your
sniper T
Frame Features //
• Rear travel: 4.7 inches (120 ±±)
with 165 x 45 stroke shock
• 29” Wheel size
• Integrated BOOST 148 x 12
dropouts
• 4.76 lbs / 2158 grams =
Standard frame w/ alloy lower
link and shock
• 4.73 lbs / 2144 grams =
SL Super Light frame w/
magnesium lower link & shock
• Injection molded top link
• Internal cable routing
• Internal seat tube cable routing
for dropper posts
• Monocoque front triangle
• H20 bottle tment
• Flack guard downtube,
chainstay, and seatstay
protection
• Tapered head tube
• Max bearings and dedicated
frame hardware
Component Spec note
The Sniper T is designed around the use of a single chain ring only. Use
of a double or triple ring set will not allow proper clearance with the frame.
Warning
Not intended for use with forks larger than 120 mm of travel.
Component Spec //
• Fork: FOX 34 120 mm with
51 mm offset, 527.1 mm axle
to crown length
• Rear shock: FOX Float DPS
165 x 45, trunnion mount,
20 mm x 8 mm reducers
• Seat post – 31.6 mm
• Headset – Cane Creek,
40, alloy cartridge (www.
canecreek.com) IS 41 top, IS
52 lower. IS = Integrated top
and lower headset
• Bottom bracket - PF92
• Rear axle – BOOST 148 x 12
with hidden lever
• Brake mount – post mount for
160 mm rotor
• Crank set - BOOST 148
compatible - single ring only
• Rear wheel - BOOST 148
compatible
