torque specifications //
Achieving proper torque is vital to ensuring the
safe performance and function of the Sniper T
frame. Failure to do so could result in sub-optimal
performance of your frame as well as premature
wear and tear of individual parts.
additional reference
In addition to this chart, torque values are laser etched
onto corresponding hardware for your reference.
16 Nm / 140 in/lbs
4 Nm / 35.5 in/lbs
16 Nm / 140 in/lbs
16 Nm / 140 in/lbs
T25 Torx Fastener: 4 Nm / 36 in/lbs
16 Nm / 140 in/lbs
7 Nm / 60 in/lbs
M8 HEX 7 Nm / 60 in/lbs
M5 HEX 14 Nm / 125 in/lbs
Derailleur Cap: 11 Nm / 100 in/lbs
Axle (non-drive side): 11 Nm / 100 in/lbs
