Intense Sniper T - Page 7

INTENSECYCLES.com // 7
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
6
Hanger Nut 130827 Hanger Nut 1
11 Nm /
100 in-lbs
7
Pivot Axle 130828 Upper Link Pivot Axle 2
16 Nm /
140 in-lbs
8
Bolt Shoulder 130829 Pivot Bolt, 10 mm Shoulder 2
16 Nm /
140 in-lbs
9
Bearing Spacer 130830
Upper Link Bearing Spacer,
19 mm OD 15 mm ID x 2.5 mm
2 N/A
10
Bearing Spacer 130831
Lower Link Bearing Spacer,
19 mm OD x 15 mm ID x 4 mm
2 N/A
11
Bearing Spacer 130832
Upper Link Bearing Spacer, 15
mm OD x 10 mm ID x 2.5 mm
6 N/A
12
Shock Bolt 130833 Trunnion Bolt, M10 Thread 2
16 Nm /
140 in-lbs
13
Bearing Sleeve 130845 Lower lInk Bearing Sleeve 1 N/A
14
Rear Axle 130846
148 x 12 mm Boost Blk
with Hidden Lever
1
11 Nm /
100 in-lbs
15
Lower Link 130825 Forged Aluminum Lower Link 1 N/A
15
Lower Link 130854 Forged Magnesium Lower Link 1 N/A
16
Cable Spacer 130856
Cable Spacer,
Lower Cable Guide
1 N/A
17
Cross Brace 130874
Upper Link
Cross Brace Assembly
1 N/A
18
Pivot Bolt 130875
Low Prole Screw,
M5 x 32, T25 Torx
2
4 Nm /
36 in-lbs
19
Clevis Bolt 130877 10 mm Shoulder 2
16 Nm /
140 in-lbs
20
Zip Tie 140053 Lower Cable Guide 1 N/A
21
Seat Collar 340343 Bolt-on 34.9 ID 1
4 Nm /
35.5 in-lbs
22
BHCS M5 X 12 410010
Water Bottle/DT Flack Guard
Bolt, Button Head, M5 X 12
4
2 Nm /
18 in-lbs
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
23
SHCS M6 x 22 410009
SHCS,
Socket Head, M6 x 22
1
14 Nm /
125 in-lbs
23
SHCS M6 x 22 410032
Cone Adjuster Bolt, Socket
Head, M6 x 22 Titanium
1
14 Nm /
125 in-lbs
24
Shock Bolt 410056
Male M6 Thread,
Left, Steel
1
7 Nm /
60 in-lbs
24
Shock Bolt 4100 66
Male M6 Thread,
Left Titanium
1
7 Nm /
60 in-lbs
25
Shock Bolt 4100 60
Female M6 Thread,
Right, Steel
1
7 Nm /
60 in-lbs
25
Shock Bolt 410067
Female M6 Thread,
Right Titanium
1
7 Nm /
60 in-lbs
26
Bearing 6802 430008
15 x 24 x 5 2RS
MAX Radial Bearing
6 N/A
27
Bearing 6800 430011
10 x 19 x 5 2RS
MAX Radial Bearing
4 N/A
28
Guard Flack
CS
500294
Flack Guard
Chainstay Top
1 N/A
29
Guard Flack
SS
500295
Flack Guard
Seatstay
1 N/A
30
Guard Flack
CS
500296
Flack Guard
Chainstay Bottom
1 N/A
31
Guard Flack DT 500297
Flack Guard
Downtube
1 N/A
32
Head Badge 500335
Head Badge
Flame Logo
1 N/A
33
Guard Flack
Strut
500510
Flack Guard
Driveside Strut
1 N/A
34
Rear Shock
Rear Shock:
165 x 45
1 N/A
35
Front Triangle Carbon, 4 Sizes 1 N/A
36
Rear Triangle Carbon, 1 Size 1 N/A
(SL)
(SL)
(SL)
(SL)
(ST)
(ST)
(ST)
(ST)
