Interchange SN5016 - Parts List

16 Ga. Medium Crown Stapler
Drives 7/16" Crown Staples (1" to 2" / 25 to 51mm)
Model No. SN5016
Item No. 64405
18
Interchange Brands Operator’s Manual
PARTS LIST FOR SN5016
NO. ORDER NO. DESCRIPTION NO. ORDER NO. DESCRIPTION
1 610560 BOLT M6X20 (Loctite 243) 50 321960 BRACKET
2 320940 BUSHING 51 321970 ADJUSTER
3 410280 EXHAUST COVER 52 421080 ADJUSTER DIAL
4 320930 EXHAUST FILTER (A) 53 630180 SNAP RING
5 320920 EXHAUST FILTER (B) 54 320860 SAFETY UPPER
6 610230 BOLT M6X30 (Loctite 243) 55 620670 SPRING
7 320910
SIDE PROTECTOR 56
420560
SAFETY UPPER GUIDE
8
110210 CYLINDER CAP
57
640020 ROLL PIN 2.5X10
9 520290
GASKET
58 320110
TRIGGER STEM
10 320890 WASHER 59 510030 O-RING 2.5X1.4
11 620380 COMPRESSION SPRING 60 420080 TRIGGER VALVE CAP
12 420610 HEAD VALVE PISTON 61 620050 TRIGGER VALVE SPRING
13 320900 PISTON STOP SEAT 62 330010 TRIGGER VALVE BUSHING
14 410270 PISTON STOP 63 510240 O-RING 8.6X1.9
15 410260 HEAD VALVE SLEEVE 64 510210 O-RING 6.3X1.8
16 510710 O-RING 54X3.1 65 420090 TRIGGER VALVE CAGE
17 510560 O-RING 41.2X2.65 66 510410 O-RING 18.3X2.65
18 321910 WASHER 67 510380 O-RING 16X1.8
19 410570 BUMPER 68 640250 STRAIGHT PIN 3X15
20 321920
DRIVER BLADE (Loctite
262)
69 320880 CONTACT PLATE
21 310370 PISTON 70 620370 SPRING
22 510510 O-RING 37.5X3.55 71 110190 ADJUST BUTTOM
23 310180 CYLINDER 72 640010 ROLL PIN 2X8
24 520130 CYLINDER SEAL 73 420590 TRIGGER BRACKET
25 510680 O-RING 50X2.65 74 420580 TRIGGER
26 110620 BODY 75 610040 BOLT M4X20
27 511010 O-RING 63.8X3.1 76 421240 MAGAZINE COVER AXIS
28 420600 CYLINDER RING 77 421250 MAGAZINE COVER
29 410460 HANDLE GRIP 78 610310 NUT M4 (Nylock)
30 630110 SNAP RING 79 321980 MAGAZINE BRACKET
31 420540 FILTER 80 620860 STOPPER SPRING
32 110310 END CAP 81 321990 PUSHER POST
33 640180 ROLL PIN 3X30 82 610120 BOLT M5X25
34 321810 STEP PIN 83 620870 DOOR SPRING
35 420950 PIN CAP 84 620880 ROLL SPRING
36 420650 SAFETY GUIDE 85 322000 PUSHER
37 210600 NOSE BASE 86 510140 O-RING 5.15X1.8
38 610220 BOLT M6X25 (Loctite 243) 87 620740 SPRING
39 210610 NOSE COVER A 88 630190 SNAP RING
40 322870 LOCK SWITCH 89 610320 NUT M5 (Nylock)
41 ###### NOT APPLICABLE 90 510180 O-RING 5.8X1.9
42 210620 NOSE COVER B 91 610110 BOLT M5X22
43 640160 ROLL PIN 3X25 92 421260 MAGAZINE
44 210630 NOSE 93 510640 O-RING 47.5X1.8
45 610100 BOLT M5X20 94 323130 STRAIGHT PIN
46 321940 SAFETY 95 511020 O-RING 1.5X1.8
47 640140 ROLL PIN 3X22 P1 D321921 DRIVER UNIT
48 321950 NAIL GUIDE P2 T420091 TRIGGER VALVE
49 610060 BOLT M5X10 (Loctite 243)
