16 Ga. Medium Crown Stapler
Drives 7/16" Crown Staples (1" to 2" / 25 to 51mm)
Model No. SN5016
Item No. 64405
4
Interchange Brands Operator’s Manual
Tool Information
Stapler Specifications: SN5016 16 Ga. Medium Crown Stapler
Tool Dimensions -
Length x Height x Width
13.78" x 12.60" x 3.94"
(350mm x 320mm x 100mm)
Weight 5.17 lbs. (2.35 kgs.) Aluminum Body
Magazine Capacity 160 Staples
Staple Shank Diameter 16 Gauge (.063" x .055" / 1.6 x 1.4mm)
Staple Crown 7/16" / 11.1mm
Staple Length 1" to 2" / 25 to 51mm
Recommended Operating Pressure 70 to 120 psi / 5 to 8.5 kgs.
Applications
Wall Sheathing, Subflooring, Roof Decking, Furniture Frames, Crate and Box Assembly
and Vinyl Siding.
Staple Specifications
FASTENERS: 16 ga. (.063" x. 055" / 1.6mm x 1.4mm), 1" to 2" / 25 to 51mm, 7/16" /
11.1mm Medium Crown Staples
WARNING: Be sure to use only the genuine staples recommended for the SN5016.
The use of any other staples can result in tool malfunction and/or staple breakdown,
leading to serious injuries.
Only the staple sizes shown in the table below can be driven with this stapler.
Dimensions of Staples
16 Gauge Medium Crown Staples
Crown Width
7/16" / 11.1mm
Leg Length
1" to 2"
25mm to 51mm
Shank Diameter
.063" x .055"
1.6mm x 1.4mm
