Intercomp PW800 - PRINTER OUTPUT CONFIGURATION; Printer Ticket (Demand) Output Details

PW800, Users
Rev O, January, 2008
22
Printer Output
The PW800 can be set to output either a printer ticket (demand) or scoreboard (continuous).
The default is a printer ticket, but this can be changed in the 'calibration' section EE-06
EE-06EE-06
EE-06.
Printer Ticket (demand)
The printer ticket output is an externally available signal designed to drive a printer or a
computer's RS-232 input.
Transmitted data:
N***xxxxx*[unit]<cr><lf>
G***xxxxx*[unit<cr><lf>
T***xxxxx*[unit]<cr><lf>
<cr><lf>
TOT***xxxxx*[unit]<cr><lf>
PIECES**xxxxx<cr><lf>
The items have the following meanings:
Item Meaning ASCII Hex ASCII Decimal
G Gross weight 47 71
N Net weight 4E 78
T Tare 54 84
xxxxxxx data
[unit] ASCII value of lb, kg, or
pcs
* space 20 32
<cr> carriage return 0D 13
<lf> linefeed 0A 10
